500gsm Polyester Needle Felt Filter Media for Dust Collector Baghouse Air Filtration

Our 500gsm Polyester Needle Felt Filter Media is a needle-punched nonwoven filtration material designed for industrial dust collection, baghouse filtration systems and dust collector filter bag manufacturing.

Made from polyester (PET) staple fibers and supported with a high-strength polyester scrim, the filter felt forms a three-dimensional fiber structure that provides good air permeability, mechanical strength, abrasion resistance and dust-holding performance.

It is widely used as filter media for industrial dust collectors and can be further processed into dust collector filter bags, cartridge filter components and other customized filtration products.

Product Overview

This polyester needle felt is designed for industrial air and dust filtration applications where reliable mechanical strength, stable permeability and cost-effective filtration performance are required.

The 500gsm construction provides a practical balance between filtration performance, durability and air permeability.

The material can be supplied as filter felt rolls or customized according to your required width, thickness, weight, air permeability and surface treatment.

Key Features

• 500gsm polyester needle felt filter media

• 100% polyester PET fiber construction

• Needle-punched nonwoven structure

• High tensile strength and good dimensional stability

• Excellent abrasion resistance

• Good air permeability

• Good dust-holding capacity

• Smooth surface for easier dust release

• Suitable for continuous industrial dust filtration

• Available with different surface treatments

• Customizable width, thickness and filtration performance

• Suitable for dust collector filter bag manufacturing

• OEM and ODM customization available

•


Technical Specifications

Actual technical specifications can be customized according to the dust type, operating temperature, filtration velocity and dust collector system.

Typical industry specifications for 500gsm polyester needle felt include approximately 1.7–1.8 mm thickness and continuous operating temperatures around 130°C, with short-term temperatures around 150°C depending on the construction and operating conditions.

Why Choose Polyester Needle Felt Filter Media?

1. Efficient Industrial Dust Filtration

The three-dimensional fiber structure created by the needle-punching process provides a large filtration surface and interconnected pores.

Dust particles are captured through the depth and surface structure of the nonwoven felt while allowing air to pass through the media.

This makes polyester needle felt a widely used filtration material for industrial dust collection systems.

2. Good Air Permeability

Properly controlled fiber density and needle-punching conditions allow the filter media to maintain a balance between filtration efficiency and airflow resistance.

Air permeability can be adjusted according to the requirements of different dust collection systems.

3. Strong and Abrasion Resistant

The polyester fiber structure provides good tensile strength and abrasion resistance, making the material suitable for repeated cleaning cycles in industrial dust collectors.

It can be used in systems where the filter media is exposed to mechanical stress and regular dust removal.

4. Suitable for Dust Collector Filter Bags

The polyester needle felt can be converted into different types of industrial filter bags.

It can be used for:

• Pulse jet dust collector bags

• Baghouse filter bags

• Industrial dust filter bags

• Cement dust collector bags

• Powder collection filter bags

• Industrial air filtration bags

We can supply the filter media fabric for filter bag manufacturers or provide customized finished products according to customer requirements.

5. Multiple Surface Treatments Available

Different finishing treatments can be applied to improve the performance of the filter media.

Singeing

Singeing helps create a smoother surface and can improve dust release during filter cleaning.

Calendering

Calendering can help control surface smoothness, thickness and permeability.

Heat Setting

Heat setting helps improve dimensional stability during operation.

PTFE Treatment

PTFE treatment or PTFE membrane lamination can be selected when higher surface filtration performance and finer particle retention are required.

Water and Oil Repellent

Water- and oil-repellent treatments can be used for applications involving moisture, oil-containing dust or sticky particles.

Anti-Static Treatment

Conductive or anti-static treatments are available for applications where electrostatic control is required.

These treatment options are consistent with the finishing choices commonly offered for polyester industrial filter media, including singeing, calendering, PTFE treatment, membrane lamination and water/oil-repellent finishes.

Industrial Applications

Our polyester needle felt filter media can be used in a wide range of industrial dust collection and air filtration applications.

Cement & Building Materials

Suitable for dust collection in:

• Cement plants

• Concrete production

• Brick manufacturing

• Limestone processing

• Building material production

• Cement grinding systems




Mineral & Powder Processing

Used for collecting dust generated during:

• Mineral processing

• Powder handling

• Grinding

• Crushing

• Screening

• Material conveying




Chemical Industry

Suitable for industrial dust filtration in:

• Chemical processing

• Pigment production

• Plastic processing

• Powder manufacturing

• Raw material handling




Metal Processing

Applications include:

• Metal processing

• Steel production

• Foundries

• Metal powder handling

• Industrial material processing




Food & Pharmaceutical Processing

With suitable material selection and finishing, polyester filter media can also be used in dust collection systems for:

• Flour processing

• Grain handling

• Food powder processing

• Pharmaceutical powder processing

• Ingredient handling

For applications requiring specific food-contact, pharmaceutical or regulatory compliance, please contact our technical team to confirm the appropriate material and treatment.

Woodworking & Furniture Manufacturing

The filter media can be used for dust collection systems handling:

• Sawdust

• Wood chips

• Sanding dust

• Furniture manufacturing dust

• MDF and wood panel processing dust




Polyester Needle Felt vs. Other Filter Media

Different industrial filtration systems require different filter media.

Polyester needle felt is particularly suitable for low-to-medium temperature industrial dust collection, where good mechanical performance, abrasion resistance and cost efficiency are important.

For higher-temperature applications, alternative fibers such as aramid, PPS, P84 or fiberglass may be more suitable depending on the actual operating temperature and chemical environment.

This is important because standard polyester filter media should not be positioned as a universal high-temperature filter material. Polyester needle felt is generally used around the ≤130°C continuous range, while specialized fibers are selected for significantly higher temperatures.

Available Customization

As a professional needle punched nonwoven manufacturer, we can customize the filter media according to your filtration system.

Customized Options

Material

• Polyester (PET)

• Polyester blended fibers

• Polyester conductive fiber

• Other fiber combinations

Weight

• 300gsm

• 400gsm

• 450gsm

• 500gsm

• 550gsm

• 600gsm

• Customized GSM

Surface Treatment

• Singed

• Calendered

• Heat set

• Water repellent

• Oil repellent

• Anti-static

• PTFE treated

• PTFE membrane laminated

Dimensions

• Customized width

• Customized roll length

• Customized thickness

Different commercial polyester needle felt products are available in approximately 300–750gsm ranges, allowing the filtration material to be selected according to filtration requirements and operating conditions.

OEM & ODM Filter Media Manufacturing

We provide OEM and ODM customization for industrial filtration materials.

Send us your requirements, including:

• Required GSM

• Thickness

• Width

• Air permeability

• Operating temperature

• Dust type

• Filtration velocity

• Dust collector model

• Surface treatment

• Required filter bag dimensions

Our technical team can recommend a suitable polyester needle felt construction for your dust collection system.

We can supply filter media rolls as well as customized filtration products according to your requirements.

Why Choose Jinhaocheng Nonwoven?

Huizhou Jinhaocheng Nonwovens Co., Ltd. is a professional manufacturer of needle punched nonwoven materials in China.

With extensive experience in nonwoven manufacturing, we provide customized needle punched felt for industrial, automotive, filtration, construction, furniture and other applications.

Our production capabilities support customized material structures, GSM, thickness, width, surface treatments and finished nonwoven products.

Factory Advantages

• Professional needle punched nonwoven manufacturer

• OEM & ODM customization

• Multiple automatic nonwoven production lines

• Large-scale production capacity

• Customized GSM and thickness

• Customized roll width and length

• Multiple functional finishing options

• Factory-direct supply

• Export experience to international markets

• Quality control and technical support




Request a Quote

Looking for 500gsm polyester needle felt filter media for dust collectors or baghouse filtration systems?

Send us your required GSM, width, thickness, air permeability and application details.

Our team can provide a suitable polyester filter media solution for your industrial dust collection system.

Contact Jinhaocheng Nonwoven today for product specifications, samples and OEM/ODM quotation.
